SECURE IN POSITION
WITH 8 SCREWS
68
ACORN 80 Installation Manual
APPENDIX 10
Rationalisation Procedures
5 The inside of the seat should look like this, with 1 arm harness feeding one arm only, and the On/Off
harness securely looped in position using self adhesive cable clamps.
6 Re-assemble back cover insert and lower back cover by securing in position with the 8 screws
removed previously.
ARM HARNESS WILL ONLY SUPPLY ONE
ARM (ROCKER SWITCH)
SEAT TO NEW
REVISION
