Acorn BASyC ABMV User Manual

ACORN CONTROLS / ACORNCONTROLVALVES.COM / 1.800.488.8999
10
CONTROL CABINET ASSEMBLY
BASyC™ systems are either pre-wired or
upgradable and the control cabinet needs to
be mounted as shown below. The Controller is
provided mounted on a custom SS bracket and
is shipped with the mounting hardware required
to attach it to the strut framing. The bottom of
each control cabinet should be positioned so
it is in line with the lowest, leftmost valve hot &
cold inlet. If you’re required to mount in another
location due to space limitations or convenience,
extensions and/or custom brackets can be
provided, please contact Acorn.
CONTROL
CABINET
