VALVE SETTINGS SCREEN
Parameter Range Default Valve
Congured
Value(1)
Notes
Outlet Temp.
Setpoint
60 to 180o F 120 Can also be changed at Alert/Alarm Screen
Installed Valves
Assignment
Loop #1 or Loop
#2
Per Order
Unless valves are added or deleted from the
system, DO NOT change
Actuator On/Off
On (checked) or
Off
Per Order
For Deactivating Actuator, turn “off”
(typ. For replacement)
BV (Ball Valve)
open
Open (checked)
Or Closed
Checked Checked
This conrms status of outlet ball valve. If you
close it, e.g. to isolate xtures or if valve is NOT
in service, uncheck this box.
Valve(s) Selection Sliders
If supplied as a BASyC™, the software is precongured for valve model selection. If
Upgrading, please make sure the sliders are selecting the correct model valves.
ALERT/ALARM CONFIGURATION SCREEN
CW Low Limit 35 to 200
o
F 35
o
F
If the CW temp. goes below this value,
an alert will result.(2)
CW High Limit 35 to 200
o
F 130
o
F
If the CW temp. goes above this value,
an alert will result.(2)
HW Low Limit 35 to 200
o
F 110
o
F
If the HW temp. goes below this value,
an alert will result.(2)
HW High Limit 35 to 200
o
F 180
o
F
If the HW temp. goes above this value,
an alert will result.(2)
CW PSI Low Limit 0 to 125 PSI 0 PSI
If the CW press. goes below this value,
an alert will result.(2)
CW PSI High Limit 0 to 125 PSI 80 PSI
If the CW press. goes above this value,
an alert will result.(2)
HW PSI Low Limit 0 to 125 PSI 0 PSI
If the HW press. goes below this value,
an alert will result.(2)
HW PSI High Limit 0 to 125 PSI 80 PSI
If the HW press. goes above this value,
an alert will result.(2)
Outlet PSI Low Limit 0 to 125 psi 0 PSi
If the mixing station outlet press. goes below this
value, an alert will result.(2)
Outlet PSI High Limit 0 to 125
o
F 80 PSI
If the mixing station outlet press. goes above this
value, an alert will result.(2)
Outlet Temp.
Setpoint Max. Limit
35 to 180
o
F 130
o
F
If setpoint is set above this value,
an alert will result.
