ACORN CONTROLS / ACORNCONTROLVALVES.COM / 1.800.488.8999
15
Pressure Sensor
Data from the pressure sensors is captured and stored by BASyC™ and used to calculate and display
mixing station HW energy and ow as well as used for data Reports and to trigger alerts and alarms.
Flow and Hot Water BTU Data
If equipped with the Flow and BTU data capability, this data will be displayed on the portable operator
interface or operating overview screen. These values may be reset by clicking on the ow or BTU values
at the Operating Overview Screen and using the links that appear.
RECIRCULATION PUMP CONTROL
If equipped with a recirculation pump option, your
BASyC™ Mixing Valve Assembly may have been
ordered with recirculation pump control. This function
is displayed, programmed and controlled through the
BASyC™ software, in lieu of the AquaStat option
available with the Command Station assembly. Acorn
provides a relay rated for the recirculation pump
provided by Acorn. If Acorn did not provide the
recirculation pump, data on the pump must be provided
upon ordering for this feature to be active. See details
later in this document on user-adjustable settings under
“RECIRCULATION PUMP SETTINGS.”
