Acrel ADL400 User Manual

- 14 -
一种颜色，“B”端接另一种颜色。
4、 RS-485 总线(从上位机通信口开始到任一被连接的仪表终端通信口)长不超过 1200
米。
Note:
1、Wiring should follow the wiring requirements;
2、Connect all the meter in the RS485 net work even some do not need to communication,
which is benefit for error checking and testing;
3、Use two color wires in connecting wires and all the A port use the same color.
4、No longer than 1200 meters of RS485 bus line.
9.1
地址表
ADDR List
仪表支持 MODBUS-RTU 协议中的 03H 命令与 10H 命令，03H 为读多个寄存器，10H
为写多个寄存器，协议数据格式请自行查询。下表为仪表的寄存器地址表：
MODBUS-RTU protocol has 03H and 10H command to read and write registers respectively.
The following chart is registers
’
address list:
表 8 通讯地址表
Table 8 communication address list
地址 Address
名称 Variable
长度
Length
读/写 R/W
备注 Notes
0000H
当前组合有功总电能
Current total electricity
4
R
整形
保留 2 位小数。
单位 kWh
(电压、电流、功率、
电能数据均为电表实
测数据，电表若存在
变比，相关数据需乘
以对应变比值)
如电能数值为 1234，
PT 为 10，CT 为 20，
则
E=1234*0.01*10*20=
2468.00kWh
其他数据如此计算
Int
Keep 2 decimal places.
Unit kWh
(the data of voltage,
current, power and
electric energy are all
measured data of the
meter. If there is a
transformation ratio of
the meter, the relevant
0002H
当前组合有功尖电能
Current spike electric energy
4
R
0004H
当前组合有功峰电能
Current peak electric energy
4
R
0006H
当前组合有功平电能
Current flat electric energy
4
R
0008H
当前组合有功谷电能
Current valley electric energy
4
R
000AH
当前正向总有功电能
Current forward active total electric
energy
4
R
000CH
当前正向有功尖电能
Current forward active spike electric
energy
4
R
000EH
当前正向有功峰电能
Current forward active peak electric
energy
4
R
0010H
当前正向有功平电能
Current forward active flat electric
energy
4
R
0012H
当前正向有功谷电能
Current forward active valley electric
4
R
