Acrel ADL400 - 概述; 型号说明; 功能列表

- 1 -
1
概述
General
ADL400 导轨式多功能电能表，是主要针对电力系统，工矿企业，公用设施的电能统计、
管理需求而设计的一款智能仪表，产品具有精度高、体积小、安装方便等优点。集成常见电
力参数测量及电能计量及考核管理，提供上 48 月的各类电能数据统计。具有 2~31 次分次谐
波与总谐波含量检测。带有 RS485 通信接口，可选用 MODBUS-RTU 协议。该电力仪表可
广泛应用于各种控制系统，SCADA 系统和能源管理系统中。产品符合 IEC62053-21 认证。
ADL400 is a smart meter designed for power supply system, industrial and mining
enterprises and utilities to calculate the electricity consumption and manage the electric demand. It
features the high precision, small size and simple installation. It integrates the measurement of all
electrical parameters with the comprehensive electricity metering and management provides
various data on previous 48 months, checks the 31st harmonic content and the total harmonic
content, realizes the remote communication and the remote control with switching input and relay
output and boasts the alarm output. It is fitted with RS485 communication port and adapted to
MODBUS-RTU .ADL400 can be used in all kinds of control systems, SCADA systems and
energy management systems. The meter meet the related technical requirements of electronic
meter in the IEC62053-21standards.
2
型号说明
Type description
3
功能列表
Function description
表 1 功能说明列表
Table 1 Function description list
功能 Function
功能说明 Function description
功能配置 Function provide
