Acrel ADL400 - 分次谐波数据

- 27 -
phase
002EH
C 相有功电能
Active energy on C
phase
0030H
正向有功最大需量
Maximum forward active
demand
0031H
发生时间：分、时
Occur time: mm-hh
0032H
发生时间：日、月
Occur time : DD-MM
0033H
反向有功最大需量
Maximum reversing
active demand
0034H
发生时间：分、时
Occur time: mm-hh
0035H
发生时间：日、月
Occur time : DD-MM
0036H
正向无功最大需量
Maximum forward
reactive demand
0037H
发生时间：分、时
Occur time: mm-hh
0038H
发生时间：日、月
Occur time : DD-MM
0039H
反向无功最大需量
Maximum reversing
reactive demand
003AH
发生时间：分、时
Occur time: mm-hh
003BH
发生时间：日、月
Occur time : DD-MM
9.3 分次谐波数据
ADL400 可选配谐波测量，统计分相 31 次谐波电压电流、总谐波畸变率、分相谐波电
压电流、分相谐波有功功率无功功率、分相基波电流电压、分相基波有功功率无功功率。
ADL400 has function of harmonic. The function include 31
st
harmonic statistics of voltage
and current, harmonic voltage and current of each phase apparently, harmonic active/reactive
power of each phase apparently, fundamental voltage and current of each phase apparently and
fundamental active/reactive power of each phase apparently.
表 11 分次谐波数据地址表
Table 11 Harmonics data address
