Acrel AMC Series User Manual

24
0104H
UBC
R
0-9999 (1 decimal place, unit V)
Uint16
0105H
UCA
R
0-9999 (1 decimal place, unit V)
Uint16
0106H
IA
R
0-9999 (3 decimal places, unit I)
Uint16
0107H
IB
R
0-9999 (3 decimal places, unit I)
Uint16
0108H
IC
R
0-9999 (3 decimal places, unit I)
Uint16
0109H
PA
R
0-9999 (3 decimal places, unit kw)
Int16
010AH
PB
R
0-9999 (3 decimal places, unit kw)
Int16
010BH
PC
R
0-9999 (3 decimal places, unit kw)
Int16
010CH
Psum
R
0-9999 (3 decimal places, unit kw)
Int16
010DH
QA
R
0-9999 (3 decimal places, unit kvar)
Int16
010EH
QB
R
0-9999 (3 decimal places, unit kvar)
Int16
010FH
QC
R
0-9999 (3 decimal places, unit kvar)
Int16
0110H
Qsum
R
0-9999 (3 decimal places, unit kvar)
Int16
0111H
PFA
R
-1000 to 1000 (3 decimal places)
Int16
0112H
PFB
R
-1000 to 1000 (3 decimal places)
Int16
0113H
PFC
R
-1000 to 1000 (3 decimal places)
Int16
0114H
PFsum
R
-1000 to 1000 (3 decimal places)
Int16
0115H
SA
R
0-9999 (3 decimal places, unit VA)
Uint16
0116H
SB
R
0-9999 (3 decimal places, unit VA)
Uint16
0117H
SC
R
0-9999 (3 decimal places, unit VA)
Uint16
0118H
Ssum
R
0-9999 (3 decimal places, unit VA)
Uint16
0119H
F
R
4500-6500 (2 decimal places)
Uint16
011AH
Zero sequence voltage
R
0-9999 (1 decimal place, unit V)
Uint16
011BH
Zero sequence current
R
0-9999 (3 decimal places, unit I)
Uint16
DO setting and status read address
025DH
Communication mode
R/W
0: None 1: 2 Stop 2: Odd 3: Even
Uint16
025EH
Pulse constant setting
R/W
16-1600 100 stands for 10000imp/kWh
Uint16
025FH
DIDO status
R
Uint16
0260H
DO1 alarm selection
R/W
0000-9999 (same as DO setting menu 5.3.3 in
SEL)
Uint16
0261H
DO1 alarm delay
R/W
0000-9999 (same as DO setting menu 5.3.3
DLY)
Uint16
0262H
DO1 hysteresis setting
R/W
0000-9999 (same as DO setting menu 5.4.3
bAnd)
Uint16
0263H
DO1 high alarm value
R/W
-9999～9999 (with the DO setting menu 5.3.3
AL.Hi)
Int16
0264H
DO1 low alarm value
R/W
-9999 ～ 9999 (along with DO setting menu
5.3.3 AL.Lo)
Int16
