Acrel DJSF1352-RN User Manual

25
means DO2 is closed, 0x0102 means DO2
is disconnected.
2.View alarm status register for alarm
status during operation
2464
开关量事件（分秒）
Switch event (Minute、
second)
RO
1
2465-2539
开关量事件记录 2-16 组
Switch event records of group
2-16
同上
Same as above
继电器一 Relay outputs one
608
设置 DO 输出类型
sets the DO output type
R/W
“0. do”表示为通信控制（此时如果 DL
Y 设置为 0 输出为电平方式，否则为脉
冲方式，如果
DLY
设置为
2
，吸合后
0.02
秒自动断开），其他为报警控制
“0. do” means communication control. (If
DLY is set to 0, the output is in level
mode , otherwise it is in pulse mode. If
DLY is set to 2, automatic shutdown will
take 0.02 seconds after pull in. Open)
1
609
输出延时时间
Output delay time
R/W
如果为
DO
输出方式，设置为
0
时，为
电平控制方式，
非 0 时为脉冲控制方式，延时设置的时
间后断开，延时设置范围 1－255 时，单
位：
0.01
秒；如果为报警输出方式，延
时设置范围 1－9999 时，单位：1 秒；
If it is DO output mode, when it is set to 0,
it is the level control mode; when it is not
0, it is the pulse control mode, and is
disconnected after the setted delay time,
the delay setting range is 1-255, unit: 0.01
seconds; if it is alarm output mode, delay
setting range is 1-9999, unit: 1 second;
1
610
不动作带区间
Non action band
R/W
1
611
电压高报警，按百分比进行
设置
High voltage alarm, set by
percentage
R/W
1
612
电压低报警，按百分比进行
设置
Low voltage alarm, set by
percentage
R/W
1
613
电流高报警，按百分比进行
设置
High current alarm, set by
percentage
R/W
1
