Remove two screws holding the wire
clamp.
2
Insert wires into two terminals for
external time signal relay and tighten
both screws. Then, tuck away the
cord and place it as shown in the
figure.
3
Secure the wire clamp with screws.
4
Insert the cover into the slot as shown
on the left. Keep pressing it down
until it hooks to the clasp.
Note: Make sure the cord is not caught
when closing the cover.
5
73
67
Wire clamp
To Next Page
