ACS A1212 MASTER - Page 42

Ultrasonic flaw detector А1212 MASTER
Operation Manual
42
ACOUSTIC
CONTROL
SYSTEMS
2
If the user attempts to delete the above-mentioned configurations, a corresponding information window will be opened
(Figure 41). Press the key to go back to the measurement mode not changing the current configuration.
Creation of new configuration
To create a new configuration based on the current one, select the line with the configuration for editing by means of the
keys, e.g.: “Basic D1771”, and make it a current one by pressing the key (Figure 39).
Press the key to change the values of the configuration parameters. Parameter values will become editable (Figure 42).
A new line will be automatically added to the end of the names list of the configurations when you change the parameter
of the configuration. This new line consists of the name of the configuration being edited with addition of the “*” character. At
Figure 41 Figure 42
