Ultrasonic flaw detector А1212 MASTER
Operation Manual
53
ACOUSTIC
CONTROL
SYSTEMS
2.3.3.2 Working with previously saved snapshots
Upon pressing the key F2 the instrument will enter the mode of viewing and deleting of the saved snapshots (Figure 54).
The functions of the icons in the STOP mode are presented in the Table 23.
Figure 53 Figure 54
Key Icon Description
F1
Go to the previous saved snapshot
Table 2 3
▼
2
