ACT ACTpro 1500 - 23 Product Specification

ACTpro 1500 and 1520 Operating and Installation Manual
Page 38
23.0 Product Specification
Number of doors 1 (expandable to maximum of 32)
Number of Users 15,000 (2 credentials per user)
User Groups 250
Time Zones 250
Door Groups 250
Log Events 5000
Browser Compatibility
Microsoft Internet Explorer 8 or 9, Firefox Version 8.0
Voltage Range:
12VDC
Current Consumption (Max):
250mA
Dimensions:
235mm x 165mm x 55mm
Weight:
455g
Relay contacting rating
Main relay 5A / 50 Vac, AUX relay 1A / 50 Vac
Operating temperature
-10 to +50 degrees C
Indoor use only
Technical Details:
Capabilities
Break glass monitoring
NetBIOS name
Status LED’s
Space for cable management
Entry & exit readers
Reader short circuit protection
Anti-passback
TCP/IP connection for ACTWin software or Web Browser
USB connection for ACTWin software
Interlocking
Features:
Controls up to 32 doors
Built-in web server (only for use with single ACTpro 1500)
DHCP / Static IP addresses
Voltage monitoring
