ACTSmart Operating and Installation Manual Rev 1.1
- 10 -
Setting Programmable Input Function:
Step Keypad Entry Operation
1 50 Set Input Function (5 – Door Release button is default)
2 0-5 Select I/O Function Code (see below for explanation of codes)
3 1-8 (optional)* Select each door this function is valid for
4 Press ✔ End programming Input Function
Setting AUX I/O 1 Function:
Step Keypad Entry Operation
1 51 Set AUX I/O 1 Function (0 - Door Contact is default)
2 0-9 Select I/O Function Code (see below for explanation of codes)
3 1-8 (optional)* Select each door this function is valid for
4 Press ✔ End programming AUX I/O 1
Setting AUX I/O 2 Function:
Step Keypad Entry Operation
1 52 Set AUX I/O 2 Function (7 - Door Alarm is default)
2 0-9 Select I/O Function Code (see below for explanation of codes)
3 1-8 (optional)* Select each door this function is valid for
4 Press ✔ End programming AUX I/O 2
I/O Function Codes:
Code Function Operation
0
Door Contact
Input required if you wish to monitor Door Forced or Door Ajar
1
Fire Alarm Override
When this input is high, the door is opened and the green LED
flashes (See Fire Alarm Override Connections diagram). If this is
wired into the Master Smart, then all doors on the network will
open.
2
Lock Door
When this input is low, the door locks and the red LED flashes
3
Card and PIN
When this input is low, then only users who enter both Card and
PIN will be admitted. This option is only valid on an ACTSmart PIN
and Prox.
4
Card or PIN
When this input is low, a valid Card or a valid PIN will open the
door. This option is only valid on an ACTSmart PIN and Prox.
5
Door Release Button
When this input is low, the door opens.
6
Interlock
This normally behaves as an input and locks the door while the input
is low. While the door relay is active or the Door Contact is open, it
becomes an active output. (See Interlock Connections diagram).
7
Door Alarm
This output activates while an alarm is present – A door alarm may
be a door forced, door ajar, tamper or duress.
8
Follow
This output follows the state of the door relay.
9
Buzzer
This output activates for Door Chime or Door Alarms
