ACTSmart Operating and Installation Manual Rev 1.1
- 3 -
Installation Notes
Installation NotesInstallation Notes
Installation Notes
• Remember to Factory Default the ACTSmart before programming
• Remember to place the supplied varistor across the terminals of the door strike coil to protect
the relay contacts
• Don’t mount the ACTSmart Prox units near RF sources (Eg mobile phones, radio transmitters,
computer monitors) or metal surfaces.
• Remember that the ACTSmart PIN and Prox units default to Card operation. Card and PIN
operation must be programmed in. (See Programming ACTSmart Options, Options 39, 40
and 41, on page 9).
• Don’t power the unit from a switch-mode power supply. Use a linear regulated power supply.
• Never use the on-board relay to switch AC mains voltage. An external relay, electrically
isolated from the ACTSmart should be used for this purpose
• Remember to change the programming code.
• Don’t power the ACTSmart from an AC power supply on a networked system. An AC power
supply may only be used on a standalone ACTSmart.
Important
ImportantImportant
Important
As with any Access Control system, always ensure there is an alternate means of escape in the
event of the unit failing to operate due to power loss or in the event of fire.
Product Specif
Product SpecifProduct Specif
Product Specification
icationication
ication
Number of Users
500 Cardholders/500 PIN codes
Supply Voltage
12 - 24V DC (linear PSU) or AC (standalone only)
Current Consumption
50mA (nominal), 80mA (maximum)
Output Current Sink
100mA
Operating Temperature
-10 to +50 degrees C
Door Open Time
0 - 255 seconds
Max. ACTSmarts per network
8
Length of network
1.4km maximum
Relay Contact Rating
5A / 250Vac
Programmable Inputs
1
Programmable Input/Outputs
2
Controller Size
Flush Mount: 100 x 110 x 20mm
Surface Mount: 100 x 110 x 35mm
Controller Weight
200 grams
Water Resistance
High IP67
Construction
Rugged Polycarbonate housing with stainless steel
keys and potted electronics.
Ordering Information
Ordering InformationOrdering Information
Ordering Information
Model Part Number
ACTSmart Proximity Only ACT 1070
ACTSmart PIN and Proximity ACT 1080
ACTSmart PIN Only ACT 1090
