Quick IO Setup:
Step Keypad Entry Operation
1 53 Set Input Output Functions (0 – is default)
2 0-9 Select a code
Prog Input AUX IO 1 AUX IO 2
0 Door Release Button Door Contact Door Alarm
1 Door Release Button Door Contact Buzzer
2 Door Release Button Door Contact Interlock
3 Door Release Button Card And PIN Interlock
4 Door Release Button Fire Override Interlock
5 Door Contact Follow Door Alarm
6 Door Contact Follow Buzzer
7 Door Contact Door Alarm Buzzer
8 Fire Override Interlock Buzzer
9 Card And PIN Interlock Follow
3 1-8 (optional)* Select each door this function is valid for
4 Press ✔ End Quick IO setup
