4 DEVICE INSTALLATION
No special training is required to install the device.
4.1 CONNECTING SOPRO 617, SOPRO 717FIRST, SOPROCARE AND SOPROLIFE INTRAORAL CAMERAS TO A COMPUTER
4.1.1 REQUIRED COMPUTER CONFIGURATION
This paragraph is linked to the cameras below:
• SOPRO 617
• SOPRO 717FIRST
• SOPROLIFE
• SOPROCARE
To use the cameras, you must make sure the computer and its peripherals do not have any usage limitations that could affect
personal safety. The following requirements should be met:
Windows® configuration:
Minimum Configuration
Recommended Configuration
Operating system
Windows® 10 SP1
Windows® 10 PRO
Processor
Intel® Core i5 – 2 cores
Intel® Core i5 – 4 cores
Memory
4 GB
8 GB or more
Hard disk
250 GB
1 TB or more
USB port
4 ports USB2.0 Hi-Speed
4 ports USB2.0 Hi-Speed
Video board
512 MB unshared RAM –
Memory compatible with DirectX 9
Chipset Nvidia or ATI / 2 GB of unshared RAM –
Memory compatible with DirectX 9 or higher
USB Chipset
Intel or NEC® / RENESAS®
Intel or NEC® / RENESAS®
Screen resolution
1 280 x 1 024
1 280 x 1 024 or higher
MAC® configuration:
Minimum Configuration
Recommended Configuration
Computer
MacBook® Pro 13’’ or iMac® 21.5’’
iMac® 27’’
Operating system
MacOS® X Monterey
MacOS® X Ventura
Processor
Intel® Core i5 or at least Apple M1 with
Rosetta2
Intel® Core i7 or at least Apple M1 with Rosetta2
Memory
8 GB
8 GB
4.1.2 MINI DOCK U_USB2 CONNECTION WITH A COMPUTER
The following section is only applicable for cameras for which a docking station is mandatory.
To integrate the MINI DOCK U_USB2, you must follow the process described hereinafter:
1. Fixation of cable on the docking station
2. Fixation of the docking station into the unit
Necessary material:
• Cutter
• Flat screwdriver
• ESD Grounding strap
