Hardware Manual
19
How to Use the Female Cable Gland
This section describes how to waterproof the cable-out or “pigtail” of the camera using the
bundled female cable gland. An exterior-grade Ethernet cable is required. The camera may or
may not have to be installed first before doing the cable connections (see related installation
procedures for details).
Before connection, prepare the following materials:
Female Cable Gland
(included in the camera package)
Exterior-Grade Ethernet Cable
(not included in the package)
NOTE: Exterior-grade cables are
already waterproof. Not included in
the package.
Washer
(included in the camera package)
Perform the following to waterproof the “pigtail” using the female cable gland:
1. Disassemble the female cable gland as shown below:
To Next Page
