E33 Hardware User’s Manual
10
4. The third piece of conduit gland goes
through the back side cover of the camera.
5. The fourth piece (locking nut) is used
to lock the gland firmly from the inside of the
back side cover.
6. Pull the network cable through the
back side cover of the camera.
7. Connect the flex conduit to the back
side cover of the camera.
