Product Specification
E33
• Device
Device Type Bullet Camera
Image Sensor Progressive Scan CMOS
Day / Night Yes
Minimum Illumination Color: 0.1 lux at F1.8 (30 IRE, 2400°K); B/W: 0 lux (IR LED on)
Color to B/W switch ISP sensor based switch; Configurable
Mechanical IR Cut Filter Yes
IR Sensitivity Range 700 - 1100 nm
IR LED IR LED x 20 (850 nm)
IR Working Distance 15 m (0 lux, 30 IRE, Max Exposure Gain)
Electronic Shutter 1/5~1/2000 sec (manual/ auto mode)
• Lens
Focal Length / Aperture Fixed focal, f4.2 mm / F1.8
Iris Fixed iris
Focus Fixed focus
Mount Type Board Mount
Horizontal Viewing Angle 64.1°
• Video
Compression H.264 HP, MJPEG
Maximum Frame Rate
vs. Resolution
15 fps at 2592 x 1944; 15fps at 2048 x 1536;
30 fps at 1920 x 1080 (Full HD 1080p); 30 fps at 1280 x 720 (HD 720p); 30 fps at 640 x 480 (VGA)
Multi-Streaming Simultaneous dual streams based on two configurations
Bit Rate 28 Kbps - 6 Mbps (per stream)
Bit Rate Mode Constant, Variable
Image Enhancement
Basic WDR; White balance: automatic, hold, and manual;
Brightness; Contrast; Automatic gain control; Digital noise reduction; Flickerless
Privacy Mask 4 configurable regions
Text Overlay User defined text on video
Image Orientation Image flip and mirror
• Network
Protocol & Service
TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP,
UPnP, SNMP, Bonjour
Ethernet Port 1, Ethernet (10/100 Base-T), RJ-45 connector
Security IP address filtering; HTTPS encryption; Password protected user levels; IEEE 802.1X network access control
• Alarm
Alarm Trigger Video motion detection (3 regions)
Alarm Response
Notify control center; Change camera settings; Command other devices;
E-mail notification with snapshots; Upload video, snapshot to FTP server
• General
Power Source / Consumption PoE Class 2 (IEEE802.3af) / 6.29W (IR on)
Weight 584 g (1.29 lb)
Dimensions (Φ x H) 77 mm x 196.74 mm (3.04" x 7.7'')
Bundled Accessories Bracket
Environmental Casing Weatherproof (IP66 rated)
Mount Type Wall, Ceiling, Corner, Pole
Operating Temperature -20 °C ~ 50 °C (-4 °F ~ 122 °F)
Operating Humidity 10% ~ 85% RH
Approvals CE, FCC, IP66
• Integration
Unified Solution Fully compatible with ACTi software
ISV Integration Software Development Kit (SDK) available; ONVIF compliant
Firmware Access Browser Microsoft Internet Explorer 6.0 or newer
