Step 8: Close the Dome Cover
1. Align the position of the dome cover shroud to the direction of the lens.
2. Tighten the three (3) screws to attach the dome cover to the camera body.
3. Remove the plastic covering the dome cover. Final installation will look like the illustration
below.
