How to Adjust the Viewing Angle
[for E918(M), E920(M), E922(M), E936(M) only]
The camera comes with the focus already prefixed, so there is no need to adjust the focus. But
the pan and tilt direction may need to be adjusted based on the camera live view.
NOTE: The following procedures are not applicable to Mini Fisheye Dome cameras.
1. Open the dome cover.
2. Slightly loosen the three (3) screws securing the lens module.
3. Turn the lens module to adjust the camera pan position.
4. Tighten the three (3) screws to fix the pan position.
