ACTi I93 - How to Waterproof the Cable Using the Cable Gland

www.acti.com
Hardware Manual
21
How to Waterproof the Cable Using the Cable Gland
1. Prepare the following items:
Cable Gland
Gland Rubber Ring
Exterior-Grade
Ethernet Cable
Waterproof Tape
NOTE: Not included in
the camera package.
NOTE: Not
included in the
camera package.
2. Detach the cable gland as shown below.
3. Insert the clamping nut through the Ethernet cable.
Gland Body
Clamping Nut
Sealing Rubber and Claw
