THROTTLE POSITION Sensor/Switch
TOYOTA
B
A
BlackYellowRed
BlackYellow
A
B B
Red
Black
Yellow
Black
Yellow
Black
Yellow
TOYOTA/NISSAN
B
B
Yellow Black
Black Yellow
Not used on some
vehicles. Perform this
test only if vehicle
mating connector has
3 wires.
Some sensors have
cable attached here.
Testing is identical.
Not used on some
vehicles. Perform
this test only if
vehicle mating
connector
has 3 wires.
