Testing Ignition Modules
3-4
Section
3
GM
4 and 5 pin
BASE
PLATE
BUSHING
*
Test clip must
touch both base
plate and bushing
*
*
Yellow
Red
Green
Black
Black
Yellow
Red
Green
