3-13
Nissan
Two-Coil System
(Photo pick-up)
Not present on
some modules.
GreenYellow
Black
14
23
14
23
**
OR
Black
Green
Yellow
Green Yellow
Black
Nissan uses two types
of connector wiring.
Module is good if either
hook-up tests O.K.
*
Yellow
Green
Black
