Actron CP9087 - Ford TFI-IV

789
6
5
4
3
2
1
Testing Ignition Modules
3-8
Section 3
Ford
TFI-IV
Test 1: Connect leads as shown.
Test 2: Move Green lead to pin 5.
Other leads remain in original position
Yellow
Black
Green
Red
END
VIEW
SIDE
VIEW
Green
END
VIEW
SIDE
VIEW
Red
Yellow
Black
Test 1: Connect leads as shown.
Test 2: Move Green lead to pin 5.
Other leads remain in original position
Ford
TFI-IV
