Actron CP9087 - Toyota

Testing Ignition Modules
3-14
Section 3
Toyota
IMPORTANT
For Toyota modules not pictured, refer to
vehicle service manual and connect as follows:
• Red lead to battery pin
• Yellow lead to coil pin
• Black lead to module ground
• Green lead to IGT pin
Red
Yellow
Green
Black
Connect BLACK test
lead to igniter mounting
hole or good vehicle
ground.
Use a paper clip to
connect test lead.
