More Uses for the Ignition Module/Sensor Tester
4-3
Continuity Checks (cont.)
12V 12V
TEST
TEST
Yellow Black Yellow Black
Ground
Connection
No
Ground
Connection
TEST
TEST
Yellow Black Yellow Black
Switch
Closed
Switch
Open
