CP9660
|
User guide | 7en
574104 REV B | 08.2018Bosch Automotive Service Solutions Inc.
Vehicle Selection
Vehicle Selection will be dis-
played for Read Codes when a
manufacturer specific DTC is
retrieved from the vehicle.
Erase Codes
The Erase function performs
the following:
9 Erases codes (both
Confirmed and Pending
DTCs) when erasing OBDII/
EOBD codes. Permanent
codes can only be erased by
the vehicle.
9 May erase Freeze Data results
depending on the vehcle.
9 Sets I / M Monitors to
not ready.
NOTICE
Perform Erase Codes
function only after
systems have been
checked completely
and DTCs have been
written down.
To erase codes from the vehi-
cle computer:
1. Set the ignition to Key On
Engine Off. Do NOT start the
vehicle. The engine should
not be running.
2. Press and hold the ERASE
key for 3 seconds then
release, or select Erase
Codes from Diagnostic Menu;
press
ENTER.
3. When the confirmation mes-
sage appears on the display,
choose one of the follow-
ing options.
• To proceed with the opera-
tion: Press
ENTER for YES.
• To cancel the operation and
return to the Diagnostic
Menu: Press BACK for NO.
4. If ABS is supported for your
vehicle, a menu is shown to
select either OBDII/EOBD,
or ABS. Select ABS to erase
ABS codes, and OBDII/EOBD
to erase emissions related
powertrain codes.
The Tool will automatically per-
form the Read Codes function
after erasing codes. The Tool
will then indicate the number of
codes remaining.
NOTICE
If after erasing codes
a DTC returns, the
problem has not been
fixed or other faults
are present.
MIL Status
MIL (Malfunction Indicator
Lamp) status indicates if the
To Next Page
