CP9660
|
User guide | 9en
574104 REV B | 08.2018Bosch Automotive Service Solutions Inc.
Since DTCs Cleared - shows
status of the monitors since
the DTCs were last erased.
This Drive Cycle - shows
status of monitors since the
start of the current drive
cycle. Refer to the vehicle
service manual for more
detailed information on
emission-related monitors
and their status.
9 Some vehicles do not sup-
port This Drive Cycle. If
vehicle supports both types
of monitors the I / M Monitors
Menu displays.
View Freeze Data
Displays a snapshot of operat-
ing conditions at the time the
Diagnostic Trouble Code was
created. See PID Definitions for
more information.
VIN
The VIN function allows the
tool to request the vehicle’s
VIN number.
The VIN function applies to
model year 2000 and newer OBD
II compliant vehicles.
System Setup
System Setup allows:
• Display contrast to
be changed
• Tool information to be viewed
• Display to be checked
• Operation of the keypad to
be checked
• Memory of the Tool to
be checked
• Units of measure to
be changed
View Data
The View Data function allows
real time viewing of the vehicle’s
computer module’s PID data.
As the computer monitors the
vehicle, information is simultane-
ously transmitted to the Tool.
View Data allows the following
items to be viewed on the Tool:
Sensor data
Operation of switches
Operation of solenoids
Operation of relays
Multiple PIDs may be sent if vehi-
cle is equipped with more than
one computer module (for exam-
ple a powertrain control mod-
ule [PCM] and a transmission
control module [TCM]. The Tool
identifies them by their iden-
tification names (ID) assigned
by manufacturer (i.e. $10 or
$1A). See PID Definitions for
more information.
