Installation and Commissioning Guide
Split Ducted ESP Indoor Unit
Installation and Commissioning Guide - Split Ducted ESP Plus/Ultima Indoor Unit
Doc. No.0525-078 Ver. 2 190925
4. Install the Sensor on the wall using the provided mounting screws
• Mount the base to the wall with screws via screw holes.
• It is recommended to use Wall Mates to secure mounting screws tightly against the wall.
• Ensure that the sensor is aligned and leveled on the wall before tightening the screws.
MOUNTING
SCREWS
WALL
WALL
MATE
SENSOR
BASE
5. Attach cover plate, as shown below
• On completion of the mounting installation, check that the Sensor is aligned and leveled on the wall.
• When fitting the cover plate, ensure that ActronAir logo is shown up right.
BACK COVER
(Mounted on the wall)
COVER PLATE
ACTRONAIR LOGO
(Up right)
To Next Page
