Installation and Commissioning Guide - Split Ducted ESP Plus/Ultima Indoor Unit
Doc. No.0525-078 Ver. 2 190925
8
Installation and Commissioning Guide
Split Ducted ESP Indoor Unit
04.03.02. For ESP Ultima
Zone Control (Sold Separately)
Part Number : LM-ZC-2W (White)
LM-ZC-2G (Grey)
Voltage : 24 VAC
Connections : RJ45 Socket
Dimensions - mm : 72.5 x 101.5 x 12 (W x H x D)
Zone Sensor (Sold separately)
Part Number : LM-ZS-2W (White)
LM-ZS-2G (Grey)
Connections : RJ Socket
Dimensions - mm : 41 x 63 x 9.5 (W x H x D)
3-Way Cable Joiner (Sold Separately)
Part Number : 4070-012
Connector Type : RJ45
Cable Length : 175mm (Included)
2-Way Cable Joiner (Sold Separately)
Part Number : 2045-121
Connector Type : RJ45
