ActSafe ACX - Page 13

Battery Release
Emergency
Descent Lever
Battery
Battery Lock
Battery Indicator
Battery Strap
(Not for Loads)
Carrying Handle
(Not for Loads)
Machine Rating label
The Ascender is supplied
with a machine label
attached to the housing.
This label must not
be removed!
The ACX Ascender
is approved under
the machinery directive
2006/42/EC for lifting
both people and
equipment with a
Working Load (WLL/
SWL) of 200 kg (440 lb).
13
