ActSafe ACX - Emergency Stop; Twisted rope and rotation

F.06 TWISTED ROPE AND ROTATION
Ensure, especially when descending, that the rope runs untwisted into the
Ascender. Twisted ropes caught into the Rope Guide can cause a rope jam
and can, in rare cases, result in rope damage.
1. Press the Emergency Stop
to immediately turn the
Ascender off.
2. Reset the Emergency Stop
by pulling out the button.
F.05 EMERGENCY STOP
Note
The Indication LED will turn
red for a short moment and
then switch off when the Power
Button is pushed while the
Emergency Stop is activated.
The Ascender cannot be
activated as long as the
Emergency Stop is pushed in.
49
