ActSafe ACX - Remote Control operation

20% 50% 100%
Activate the Remote
Control by pushing
the Power Button.
By pushing either the
‘UP’ or ‘DOWN’ button
the Remote Control will
take over the control
of the Ascender and
the Ascender will
stop immediately.
Select between 3
speeds in both ascent
and descent: 20%,
50% and 100%.
The speeds can be
set by a short push
of the ‘UP’ or ‘DOWN’
button and the LED
bar will indicate the
selected speed.
The green LED on
the Ascender will turn
blue to indicate control
has been taken over
by the Remote Control.
1. Activation and connection 2. Take control of the Ascender 3. Set the Ascender speed
The green ‘POWER‘
LED will show and the
blue ‘LINK’ LED will
start to blink for a
few seconds whilst
a connection is
established with
the Ascender.
Once connected, the
blue ’LINK’ LED on the
Remote Control will
be lit continuously.
F.08 REMOTE CONTROL OPERATION
Short
press
Short
press
