i
Remote Control Battery
The Remote Control unit is equipped with
an internal battery which is charged via the
supplied USB cable. Complete charging
will take up to 150 minutes via a computer,
or 75 minutes with the supplied adaptor.
The USB Connection Point can be found
on the bottom of the Remote Control under
the protection cap that can be unscrewed.
CAUTION
Make sure that the Remote Control has visual contact
with the Ascender to ensure safe operation and
maximum range.
When using the Remote Control, should the unloaded
rope be held by an operator to ensure that the rope
can run unhindered into the Ascender while lowering.
Uncontrolled rope running into the Ascender can
cause a rope jam and eventually rope damage.
RECOMMENDATION
Always use the Remote Control in combination
with a stop knot at the end of the rope.
The power LED on the Remote Control
will turn red at 20% charge. The power
LED will fl ash during charging and will
be steady lit (green) once charging
is completed.
54
