VALUE COMMENT
PERFORMANCE/PART
Rope
Personnel Lifting – EN 1891 A
11 mm (7/16”), Equipment
Lifting — ActSafe ELR
See our website for tested ropes.
Polyamid ropes should be soaked before fi rst use.
See section C.01
Safe Working Load
(SWL /WLL)
200 kg (440 lb)
Ascent speed
0-24 m/min (0-78 ft/min)
Descent speed
0-25 m/min (0-82 ft/min)
Emergency descent speed
0-25 m/min (0-82 ft/min)
Battery range
Approximately 200 m at 100 kg
(656 ft at 220 lb)
At 20°C (68°F), continuous ascending.
See section E.02
Charging time
90 min Charging time for an empty Battery
Temperature range
-10°C (14°F) to 40°C (104°F) Values apply to ambient temperature.
See E.02 for more info
Over heating protection
Yes
Ascender weight
10.5 kg (23,15 lb) Ascender weight with Battery is 13 kg (28,7 lb)
Battery weight
2.5 kg (5.5 lb)
Dimensions
33 x 28 x 27 cm (13 x 11 x 11”)
Remote Control
Range – up to 150 m (492 ft)
Radio frequency – 2.4 GHz
The remote must have visual contact with the
Ascender to ensure maximum safety and range
Water/dust resistance
IP 55
Noise level
76 dB
Max windspeed
12 m/s (39 ft/s) Weather conditions should be stable and
favourable to not affect the safety of personnel
and/or lifting operation
70
