Acura MDX 2003 User Manual

Slide the new wiper blade into the
holder until the tabs lock.
Examine the new wiper blades. If
they have no plastic or metal rein-
forcement along the back edge,
remove the metal reinforcement
strips from the old wiper blade and
install them in the slots along the
edge of the new blade.
Remove the blade from its holder
by grasping the tabbed end of the
blade. Pull firmly until the tabs
come out of the holder.
Slide the wiper blade assembly
onto the wiper arm. Make sure it
locks in place.
Front only:
Lower the wiper arm down against
the window.
Windshield: Lower the passenger’s
side first, then the driver’s side.
6.
7.
4.
5.
3.
Wiper Blades
Maintenance
329
BLADE
BLADE
REINFORCEMENT
０２／０７／３０ ２２：１５：０３ ３１Ｓ３Ｖ６２０ ０３３４
