ACV Prestige - Solo 80;110 & Excellence Burner Components

31
6.0 Replacement Parts
1
3
6
4
2
5
8
7
9
Fig. 9: PRESTIGE Solo 80/110 & Excellence Burner Components
Item Part # Description
1 PARKIT12 Combustion Chamber 2-in-1 Insulation
2 PARKIT14 Burner Head Assembly (with Gasket)
3 PARKIT11 Blower Assembly (with Gasket)
4 PARKIT18 Blower Clamp
5 PARKIT19 Blower Gasket
6 PARKIT15 Burner Plate Assembly
7 PARKIT17 Gas Valve
8
PARKIT10 Venturi - Solo 80
PARKIT20 Venturi - Solo 110
9 PARKIT16 Igniter Assembly
