ACV Prestige - Solo 155;175;250 Burner Components

32
6.0 Replacement Parts
3
9
6
2
1
7
8
4
5
Fig. 10: PRESTIGE Solo 155/175/250 Burner Components
Item Part # Description
1
PARKIT42 Combustion Chamber 2-in-1 Insulation - Solo 155
PARKIT52 Combustion Chamber 2-in-1 Insulation - Solo 175 & 250
2 PARKIT54 Burner Head Assembly (with Gasket)
3
PARKIT51 Blower Assembly (with Gasket) - Solo 155 & 175
PARKIT61 Blower Assembly (with Gasket) - Solo 250
4 PARKIT18 Blower Clamp
5 PARKIT19 Blower Gasket
6
PARKIT45 Burner Plate Assembly - Solo 155
PARKIT55 Burner Plate Assembly - Solo 175 & 250
7 PARKIT59 Gas Valve
8
PARKIT30 Venturi - Solo 155
PARKIT40 Venturi - Solo 175
PARKIT50 Venturi - Solo 250
9 PARKIT56 Igniter Assembly
