ADA MP-1 Owner’s manual
7.0 SPECIFICATIONS
EQ Bass and Treble boost/cut 16dB:Mid and Presence boost/cut
12dB.
TUBE COMPLEMENT Four stages of gain using two low noise 12AX7 A/202S.
MIDI Specification:1.0 Rev. 3.3:
Channel: 1-16, OMNI, OFF; Program Change: external
programs 1-128, internal memory 1-128 and OUT (bypass);
MIDI Time Code (MTC): recognized in Level 3 software;
Parameter Change & Dump: SYSTEM Exclusive.
CHORUS, DEPTH 0 (none) to 7:1.
CHORUS, RATE 0.1 sec. to 10 sec. and 0ff (0).
INPUT, FRONT PANEL One, 1/4" phone jack, high impedance (1 meg ohm) wide
range input.
INPUT, REAR PANEL One, 1/4" phone jack, active balanced (30k ohm). Ring, tip,
sleeve.
OUTPUTS Two, single-ended 1/4" phone jacks, Synthesized
complementary stereo outputs. Switchable from
instrument to line level.
EFFECTS LOOP, SEND Single-ended 1/4" phone jack. Variable from instrument to line
level. Maximum drive on send line is + 19dBm.
EFFECTS LOOP RECEIVE Single-ended 1/4" phone jack. Maximum signal level is
+30dBV.
EFFECTS LOOP, LEVEL Provides 20dB of inversely proportional boost or cut to the
send/receive signals. Interfaces with low level and line level
effects.
HEADPHONE, LEVEL Provides full mute to +17dB above internal signal level.
Max. Output +12dBm.
HEADPHONE (JACK) 1/4" stereo phone jack. Drives headphones of 600 ohms or
more.
POWER CONSUMPTION 12 watts.
POWER 120VAC, SO/60Hz.
DIMENSIONS L-10.S" X W-19" X H-1.7S" (483 X 44 x 269 mm).
WEIGHT 61bs (2.72 kg); 81bs (3.63 kg) shipping.
OPTIONS 220V AC, SO/60Hz, Extended 3 year warranty, Software
updates, ADA replacement tubes.
ACCESSORY MC-1 MIDI Foot Controller.
All specifications subject to change without notice.
