ADA MP-1 Owner’s manual
10.0 SYSTEM EXCLUSIVE MESSAGES
RESET DEVICE
<F0> System Exclusive Message 10 (SYSEX)
<00> ADA Identifier
<cc> Channel number
<dd> Device number
<01> Reset Device Command
<xx> Message Checksum
<F7> End of System Exclusive (EOX)
.Causes the specified device to perform a reset operation.
.Specifics of the reset are device dependent.
.No response is sent by the device.
RUN DIAGNOSTIC TEST
<F0> SYSEX
<0D> ADA Identifier
<cc> Channel number
<dd> Device number
<02> Run diagnostic test command
<tt> Test number
<xx> Message checksum
<F7> EOX
.Causes the specified device to run a selected diagnostic test routine.
.Test 00 is equivalent to the power-on diagnostic.
.Other test numbers are device specific.
.No response is sent by the device.
REPORT DIAGNOSTIC STATUS
<F0> SYSEX
<0D> ADA Identifier
<cc> Channel number
<dd> Device number
<03> Report diagnostic status
<xx> Message checksum
<F7> EOX
DIAGNOSTIC STATUS RESPONSE
<F0> SYSEX
<00> ADA Identifier
<cc> Channel number
<dd> Device number
<00> ResponselD
<03> Reponsetype
<ss> Response (may be one or more bytes)
<xx> Message checksum
<F7> EOX
.Retrieves the most recent diagnostic result.
.The first byte of the response = 0 if no error occurred, and ne 0 if an error occurred.
.Some tests may return multiple bytes on a device and test specific basis.
Page 20 of 26
