ADA MP-1 Owner’s manual
the ^ V switches, the bank switch and/or a number from 0 to 9. To record the change, press
the switch again or press the PRGM button to continue.
IN EDIT MODE:
VOICING
Allows choice for each program of Clean Tube, Distortion Tube, or Solid State circuits. Use
^
V switches to step through choices when Voicing switch is selected.
OVERDRIVE 1
Attenuates pre-tube input signal. Higher gain levels of Overdrive 1 result in higher frequency
harmonic saturation.
OVERDRIVE 2
Attenuates inter-tube signal. Higher levels of Overdrive 2 result in fuller harmonic saturation.
In the Solid State mode, Overdrive 2 sets the level of compression.
MASTER GAIN
Post-tube, pre-EO gain.
BASS
Narrow band low frequency EO control adjustable in 2 dB steps
± 16 dB.
MID
Wide band mid frequency EO control adjustable in 2 dB steps
± 12 dB.
TREBLE
Narrow band high frequency EO control adjustable in 2 dB steps
± 16 dB.
PRESENCE
Wide band high frequency EO control adjustable in 2 dB steps
± 12 dB.
CHORUS DEPTH
Adjusts the sweep depth from 0 to 100% for a maximum range of 7:1. When the Chorus Rate
is set to 0 (off), the Depth control will vary the delay time to create different filtering and
doubling effects.
CHORUS RATE
Adjusts the speed of the sweep from.1Hz (1 cycle per 10 seconds) to 10Hz (10 cycles per
second), or off (0).
EDIT
Places MP-1 into the Edit mode. The display reads “Edit” until a parameter is selected.
Display then shows the value of the selected parameter. Use the
^ V buttons to
decrease/increase the value of the selected parameter.
STORE
Places the MP-1 into the Store mode. Stores any current or edited program to any internal
memory location. Press the STORE button followed by a memory location. LED indicates
Store mode is engaged. LED turns off after storage is complete. If you decide not to store the
current program, but you've already pressed the STORE button, you can exit the Store mode
by pressing STORE again.
Page 7 of 26
