About the Adaptec RAID 71605/71605Q
The Adaptec RAID 71605/71605Q is a SAS RAID controller with these features:
4 internal mini-SAS HD connectors
Ext. Alarm connector
HDA mode connector
CN0
CN1
CN2 CN3
Daughterboard
connector
PCIe x8 connector
Mounting bracket
Low-prole MD2 SFF card sizeForm Factor
PCIe Gen3Bus compatibility
x8PCIe bus width
6 Gb/s per portData transfer rate
16Phys (Unied Serial Ports)
1024 MB DDR3Standard cache
4 mini-SAS HD x4 (SFF-8643)Connectors, internal
16 direct-attached (or up to 256 with expanders)Maximum number of disk drives
71605Q: Up to 16 solid state drives, 2TB capacity, max. See the
maxCache compatibility list at www.adaptec.com/compatibility.
maxCache SSD support
IBPI and SGPIO (Serial General Purpose Input/Output)Enclosure Support
YesOnboard speaker
Adaptec Flash Backup Module AFM-700 (71605: optional, sold
separately; 71605Q: standard, pre-installed)
Zero Maintenance Cache Protection
Module
