About the Adaptec RAID 71605E
The Adaptec RAID 71605E is a SAS RAID controller with these features:
4 internal mini-SAS HD connectors
Ext. Alarm connector
HDA mode connector
CN0
CN1
CN2 CN3
PCIe x8 connector
Mounting bracket
Low-prole MD2 SFF card sizeForm Factor
PCIe Gen3Bus compatibility
x8PCIe bus width
6 Gb/s per portData transfer rate
16Phys (Unied Serial Ports)
256 MB DDR3Standard cache
4 mini-SAS HD x4 (SFF-8643)Connectors, internal
16 direct-attached (or up to 256 with expanders)Maximum number of disk drives
IBPI and SGPIO (Serial General Purpose Input/Output)Enclosure Support
YesOnboard speaker
NoZero Maintenance Cache Protection
Module
