8230 Optical Power Meter Operation Manual
1.4 Connectable Sensors
1-5
• 82017A
The 82017A is a general-purpose, thin-type sensor used for the TQ8210 and TQ8215. When this sensor
is used for the 8230, option 70 must be installed. Wavelengths ranging from 400 nm to 1100 nm can be
measured and the calibration wavelength is 850 nm. The typical value stored in the optical power meter
is used as wavelength sensitivity correction data.
• 82015
The 82015 is a general-purpose, cylindrical-type sensor used for the TQ8210 and TQ8215. When this
sensor is used for the 8230, option 70 must be installed. Wavelengths ranging from 800 nm to 1600 nm
can be measured and the calibration wavelength is 1300 nm. The typical value stored in the optical pow-
er meter is used as wavelength sensitivity correction data.
• Q82018A
The Q82018A is a sensor with the FC connector used for the TQ8210 and TQ8215. When this sensor is
used for the 8230, option 70 must be installed. Wavelengths ranging from 800 nm to 1650 nm can be
measured and the calibration wavelength is 1300 nm. The typical value stored in the optical power meter
is used as wavelength sensitivity correction data.
*: This product has been discontinued.
For more information, refer to section 8.2, "Optical Sensor Specifications."
For more information on the outline and dimensions, see the dimensional outline drawing for each sensor in
the appendix.
For more information on option specifications, refer to Table 1-5 Sensor Option.
The existing optical sensors 82311, 82321, 82312, 82322, 82313, 82323, 82314A, 82324A and 82314W can
be used in addition to the optical sensors described in this manual.
The following table shows old and new model numbers of optical sensors. When using the old models, this
manual should be read implying that the new model numbers are their corresponding old model numbers
respectively.
There is no difference in specifications between the new and old models.
Table 1-3 Old and New Model Numbers of Optical Sensors (1 of 2)
New model number Old model number
Thin-type general-purpose optical sensor
Wavelength: 390 to 1100 nm
82311B 82311
Cylindrical type general-purpose optical sensor
Wavelength: 390 to 1100 nm
82321B 82321
Thin-type blue-violet optical sensor
Wavelength: 390 to 450 nm
82312B 82312
Cylindrical type blue-violet optical sensor
Wavelength: 390 to 450 nm
82322B 82322
Thin-type high-power optical sensor
Wavelength: 390 to 1100 nm
82313B 82313
Cylindrical type high-power optical sensor
Wavelength: 390 to 1100 nm
82323B 82323
To Next Page
