5. SPECIFICATIONS
5-1
5. SPECIFICATIONS
5.1 Optical Sensor Specifications
All accuracies are guaranteed for one year at a temperature of +23C  5C and a relative humidity of 70%
or less.
Item Specification
Model
82311B
(General-purpose)
82312B
(For blue-violet light)
82313B
(For high power light)
Wavelength range 390
to 1100 nm 390 to 450 nm 390 to 1100 nm
Power range
Display in dBm -60 to +17 dBm -50 to +20 dBm -50 to +23 dBm
Display in W 1 nW
to 50 mW 10 nW to 100 mW 10 nW to 200 mW
Beam spot 3 mm or more 1 mm or more 0.1 mm or more
Light receiving element Si photodiode
Light receiving area Approx. 9.5 mm 
9.5 mm
Approx. 10 mm 
10 mm
Approx. 8.5 mm
Effective light receiving area *1 Approx. 8.5 mm 8.5 mm Approx. 6 mm
Calibration wavelength *2 780 nm 405 nm 650 nm
Measuring accuracy (when 1 mW is input)
2.5% (at calibration wavelength)
3.5% *3
(400
to 1000 nm)
3.5%
(390 to 450 nm)
3.5%
(400 to 1000 nm)
Wavelength sensitivity correction range 390
to 1100 nm 390 to 450 nm 390 to 1100 nm
Shape Thin type
Separation from a sensor section *4 Impossible Possible Possible
Dimensions (width)  (height)  (thickness
of the light receiving section) mm
18 180 3.2 18  18 
*1: Relative sensitivity to the center is within the 10 % range.
*2: Can be added by using options. (A calibration wavelength other than the standard specification can be
selected by using the calibration wavelength selection function.)
*3: Only when Option+20 is specified
*4: The warranty does not include cut cables and/or damaged or degraded elements caused by continuous con-
necting and disconnecting to the sensor section.
