Video display (DDC) information
The Display Data Channel (or DDC) is an industry standard scheme that allows
video displays to declare their capabilities to the computer’s video adapter
circuitry, allowing the latter to optimise their outputs accordingly. Since the
widespread adoption of the scheme, video adapters have become increasingly
dependent on receiving relevant DDC information during startup, before they
will output anything more than a rudimentary video signal.
It is not possible to transmit DDC data back from the video display that is
attached to the remote module to the computer’s video adapter. Therefore,
during startup of the local module, it will search for a video display connected to
its local feed-through connector:
• Ifalocalvideodisplayisfound,itsDDCinformationwillbecomparedto
the information already stored and, if different, will be copied, stored and
presented to the video adapter upon request.
• Ifnolocalvideodisplayisfound,thelocalmodulewillmakeavailableits
previously stored set of DDC parameters to the video adapter upon request;
or, if none were stored, a default set.
In either case, the DDC information taken by the video adapter will be used
to determine the video output that is sent via the X-USBPRO modules to the
remote video display.
If you find that the default DDC information is not completely suitable for your
remote display, try temporarily connecting your remote display to the video out
port of the local module. When the local module is powered up, it will read and
store the DDC information from your display. You can then return the display to
its remote position and the new DDC information will be used at every power
on.
Note: For MS2 variants, the dual video channels are handled seprately.
Therefore, if you wish to capture both sets of DDC information, you will need
to temporarily connect both of your remote video displays to the video output
ports of the local module.
DDC indications
When power is first applied to the local module (either from
the computer’s USB port or an optional power adapter) it will
search for valid DDC data on its video out connector. During
this process, the green indicator (built into the link connector)
will flash to indicate its progress:
• IfnovalidDDCinformationislocated,thegreenindicator
will give one very short flash, representing an attempt to
read data. No changes will be made to the information already stored within
the local module.
• IftheDDCinformationisthesameasthatalreadystored,nochangewillbe
made and the green indicator will give one single flash as the information is
checked and normal operation resumes.
• IfdifferentDDCinformationislocated,thegreenindicatorwillashrapidly
for 2 to 3 seconds while the new information is stored. A single flash will
then be given as the information is checked and normal operation resumes.
The local module’s green indicator also provides fault indications to assist with
troubleshooting:
• Twoashes-Checksumerrorpriortocopying-noinformationwillbe
programmed.
• Threeashes-Toomuchdatatotintothemodule-themodulecanhold
a maximum of two pages of DDC information.
• Rapidashingfollowedbyfourashes-datawaslostduringcopying-the
default data was substituted. Repeat the power on process.
• Rapidashingfollowedbyveashes-Checksumerrorduringcopying-
the default data was substituted. Repeat the power on process.
