ADJ 1226100300 - Page 12

ADJ Products, LLC - www.adj.com - Flat Par QA12XS User Manual Page 11
Master-Slave Operation:
This function will allows you to link units together to run in a Master-Slave
configuration. In a Master-Slave configuration one unit will act as the
controlling unit and the others will react and copy the controlling units
operation. Any unit can act as a Master or as a Slave however, only one
unit can be programmed to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit.
Use standard XLR data cables to link your units together. Remember
that the Male XLR connector is the input and the Female XLR con-
nector is the ouput. The first unit in the chain (master) will use the
female XLR connector only. The last unit in the chain will use the
male XLR connector only.
2. Connect the rst “Slave” unit to the “Master.”
3. Set the “Master” unit to your desired mode of operation. The “Slave”
unit will now follow the “Master”.
Flat Par QA12XS Operating Instructions
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 7 xtures maximum. After 7 xtures you will need to
use a new power outlet. They must be the same xtures. DO NOT
mix xtures.
Flat Par QA12XS Power Cord Daisy Chain
ADJ Products, LLC - www.adj.com - Flat Par QA12XS User Manual Page 16
Flat Par QA12XS 4 Channel Mode
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
Flat Par QA12XS 5 Channel Mode
